Hundreds of flow-diagramming featuresWdfDiagram provides all major features of MindFusion WinForms and ActiveX components but uses the advantages of Microsoft's latest graphical subsystem. You can use WpfDiagram to create workflow processes, object hierarchies and relationships, graphs and networks, entity-relationship / database charts, IVR systems, industrial automation processes, genealogy trees, algorithms and flowcharts, organizational schemes, XML documents, classification hierarchies and more.

Constraints PropertyScreenshot showing boxes constrained to move only horizontally via the Constraints property of the Node Class.

DialogueScreenshot showing a diagram that defines a dialog that can be conducted by an automated system such as an IVR system. You can define your own nodes in the dialogue.

Hierarchical GroupingScreenshot showing hierarchical grouping and collapsing/expanding subtrees in the hierarchy.
